500/1000/2000kg/h Soap Noodles Making Machines, Soap Saponification Machines https://www.detergentandsoapmachine.com/products-2-72-p.html
For more details, pls directly contact with Jenny,
Tel/Whatsapp/Wechat /Telegram: 0086 156 1765 1038, Products photos of Toilet Laundry Soap Production Finishing Line: Product description of Toilet Laundry Soap Production Finishing Line: 1. This toilet laundry soap production line take soap noodles as raw materials. 2. The production starts with mixing soap noodles and perfume and other additiontives. 2. Then the mixed soap noodles enters in the three roller miller by conveyor belt, where soap thin sheets are made. 3. The soap thin sheet then converted into desired long strip soap by the double screws vaccum soap plodder machine. 4. Then the long strip soap are cut into the different sizes of soap bars required size by cutting machine. and the toilet soap is printed different shapes by soap stamper/soap printing machine. 5. Finally, the soap bars are packed by packing machine if needed. 6. Soap bars can be made 60g,120g,200g,260g,and so on Features of Toilet Laundry Soap Production Finishing Line: 1. The finishing lines of Series for toilet and translucent soap bring together all components that are most reliable, most durable, supplied by the most famous vendors in the world. 2. The mechanical design is tend to be simplified, more robust, low energy consumption, low off-stream rate, easy to be maintained ,more people-oriented and with good view both outside and inside of the machines. Advantages of Toilet Laundry Soap Production Finishing Line 1.Full automatic production line 2.Capacity can be from 75-2000kg/h. 3.Soap size depends on client demands 4.Good performance & high efficiency Machine parameter of Toilet Laundry Soap Production Finishing Line:
Mixing the material and neat soap, also crushing the bad soap bars.
3 roller miller
1350*1670*1050mm
7.5kw
50Hz
380v
rubbing soap material
Semi-finished product conveyor
4500*730*1650mm
2.2kw
50Hz
380v
convey soap pieces
Double-screws vacuum soap plodde
3750*900*2100mm
24.5kw
50Hz
380v
vacuum ploddering
Vacuum pump
--
1.5kw
50Hz
380v
vacuum bubble pumping
Laundry soap bar cutting machine
800*360*800mm
3kw
50Hz
380
cut the soap into different sizes and weight, and print words and logo on the soap bar
Toilet soap stamper machine
800*300*1000mm
3KW
50Hz
380v
print different shapes toilet soap with different logo
Products conveyor
3000*500*1000mm
0.75kw
50Hz
380v
Convey products
Soap chiller
1500*700*1700mm
2.5kw
50Hz
380v
auxiliary equipment of the soap printer
Soap packaging machine
3900 * 940 *1500mm
3kw
50Hz
380v
packing toilet and laudnry soap bars
Different capacity of Toilet Laundry Soap Production Finishing Line : Toilet Soap Production Line: 100/200/300/500/800/1000kg/h Laundry soap production line:100/200/300/500/800/1000/1500/2000kg/h
